Aqua refrigeratum stupra Chiller

Ambient Temperature Cryogenic Single Compressor Duplex Compressors Aqua refrigerata stupra Chiller

Aqua refrigerata cochlea una compressor duos scaena chiller (-45℃)

Compressores cochleae conventionales unius-scaenae minimum efficiunt temperiem evaporationem minimam -40℃. Perveniens ad inferiores temperaturas systematis stadii duos stadios requirit. Simul condiciones premendi ratio condiciones significantes provocationes ponunt pro compressoribus unius scaenae traditis, incluso nimiae lacus et elevatae missione temperaturae. Hae limitationes efficiunt in humilitate efficientiae et constantiae in extrema operante condiciones. Compressio una-unitas has quaestiones efficaciter solvit.
Compressor duo scaena ratio praebet notabiles utilitates sicut vestigium compactum et facilior moderatio. Compressio systemata unica comparata, altam efficaciam et superiorem fidem tradit. Apta variis industriis excepta refrigeratio humilis temperatura producta, refrigeratio processus, pharmaceutica, et biochemista.

Aquae refrigeratae cochleae cascade chiller (-55℃)
Haec series ad minimum exitum aquae temperaturae usque ad -8℃ attingit. Nostri ultra-low temperies chillers cascade refrigerationis unitates sunt amplificatae a nostris core technical team, decades experientiae leveraging in medio-ad-low temperatura Chiller design et integrare technologias provectas ex versos domesticos et internationales. Evidentiam inducunt altitudinem, peculi industriam, comitatem environmental, constantiam eximiam. Unitates Cascades principaliter adhibentur ad refrigerationem secundariam ab -35℃ ad -80℃, adhibitis in pharmaceuticis et chemicis industriis, reactorem crystallizationem, altum vacuum distillationis, aerospace componentium probatio, recuperatio gasi, refrigeratio cibi, vas repositionis cryogenic, et aliae ambitus humilis temperaturae.

+86 18921753771

[email protected]

Ex authentica technica Europaea derivata.
Core technologica virtute consequat.

PREV：Aqua refrigeratum stupra inundata Chiller
DEINDE：Nullus proximus articulum

Product Description
Product Specifications

Aqua refrigerata cochlea chiller
Optiones Product
Aqua salsa evaporator
· totus calor recuperatio / pars calor recuperatio
· Praecipua potentia copia
· Strenuus industria ordinatio
· Pump / turrim refrigerationem control
Communicatio remota · connect
·Frequentia conversionis

Products features
·QTwin cochlea compressor ensis adhibita cum efficientia alta, humilis soni campestris minus circumdatio et temporis longi operatio.
· Quattuor scaenae imperium vel 0%-100% automaliae constitutiones.
· Utere PL*C microcomputer control de SIEMENS Germaniae, cum screen tactus LCD, machinae humanae machinae tam Anglicae quam Sinicae.
·Protegium naufragii: princeps et humilis pressionis praesidium, air- sionis tutela. oleum planum tutela aqua fluens praesidium, contrarium et defectus Phase praesidium aqua frigida anti-sidiis, aqua refrigerans supra praesidium.
· Latius temperatura aquae frigidae variabilis temperaturae industriae requisitis ad frigiditas occurrit.

Product speciem
· Refrigerant:R134A/R407C
·Condenser: factor foedum 0.044m2,9C/KW
·Potestas copia:380V/3P/50Hz
· Evaporator/condenser aquae max pressura gutta: 1.0MPa
· Evaporator: factor foedum 0.018m2,9C/KW
· Licitus voltage fluctuant: ±5%
·Permissa frequentia fluctuant: ± 2%

Compressor
Select semi-clausus 5:6 asymmetric compressor gemelli cochleae notae inclitae mundi. Facultas lacus sigilli scapi nulla est. Usura gyrationis exhauriendi consilium, novissimae progressionis lineae quartae generationis, optimize celeritatem circumferentiae, optimum calces consilium ut unitas maiorem compressionem efficientiam habeat, cubiculi motoris compressionis cubiculi integraliter praecisionem altam eiciunt. Duplex pressionis rotor habitationem fortissimam nullam expansionem compensat, etiam in statu altorum pressionis, et strepitum affabiliter reducit.

Calor exchanger
Condenser et evaporator huius seriei unitatis adoptat testam et fistulam caloris commutatoris, utens nova alta efficiens caloris commutatoris structura, calor commutator antecedens et efficax caloris commutationis fasciculus cum, singularibus notis geometricis et, auctus tubus nucleatis ferventis, requiritur vaporiza- tionis nucleus, robora fluidum in tubo et mora perturbationat in eodem tempore, in aqua parte melioris et effectionis, caloris trans- ferendi ad meliorem efficiendam, et, ad nucleum augendum ferventis, requiritur vaporiza- tionis, confirma fluidum in tubo et mora perturbationat in eodem tempore, ad optimam partem efficiens, calor transfundens ad melius previousdesign, singulare consilium caloris translatio efficientiae 30% augetur. Tubus evaporator evaporationis cum sulcus cochleae interioris in dente concavo exteriore auctus calor translatio technicae tubi condensoris interioris cochleae sulcus dromonis dentium technologiae, evaporator et condenser calor transferendi efficientiam et evaporationem caliditatem auget, et tandem meliorem vim efficiendi rationem unitatis.

PL
Bonum interactivum interactivum omnes-Chinese est consequi functionem latae sententiae ante statuas temporis apparatus LCD propono, subtilis vigilantia unitas operans ad optimum statum, tactus tabula signatus, IMPERVIUS, dustproof, corrosio-repugnans, longaevus vita. Instructus refrigerantibus soleatus, aquae refrigerationis soleatus et turris refrigerationis ventilationis munus interlock control.

Humilis temperatus chillers
SW series frigiditatis temperatae humilis innixa notis notis sicut cochleae semi-hermeticae exercitus compressoris, in colum colum, colum, oleum separatorum constructum, valvae salutis et moduli tutelae, sine lacus, sono humilis, operatio stabilis.

Aqua refrigerata cochlea una compressor duos scaena chiller (-45℃)
Product Features
Modularis Configurationis Design: modularis designatio pro gradibus pressurae altae et humiles efficit vicissitudinem inter diversos pressionis gradus.
· Summus Pressura Tempus Exonerare Slider: Patented automatic exinanitio mechanismum pro scaena summus pressura. Purus consilio mechanicus necessitatem partium externarum sicut valvularum solenoidalium eliminat, ut simplex et efficax comprimens initium leve.
· Inaedificata in Suctione Perscriptio Valvae: Ad exempla maiora, valvae constructae in suctu reprimendam structuram ad spatium institutionis reducendum incorporat.
· Optimized Motor Cooling Flu Path: Enhances compressorem efficientiam dum certificam refrigerationem motricium manans, operationem per amplissimum amplitudinem praestanti aptabilitatis elaborans.
· Integrated Economizer Aeris Filter: Firmum compressorem tutelam praebet et configurationem systematis simplificat.

Aquae refrigeratae cochleae cascade chiller (-55℃)
Product Features
· Lata Temperature Range: Temperatura secundaria refrigerans ab -35°C ad -80°C.
· High Reliability: Cochleae semi-hermeticae compressores ad augendae operationis efficientiam augendae sunt, dum eliminatis ultrices constitutionibus communes in compressoribus apertis. Reducit refrigerantes top-ups et hastile sigillum supplementum, ad operationem continuam procurans.
· Imperium plene Automatum: Emploes Siemens PLC technologiae provectae ad operationem plene automated.
· Maximum Efficiency & Energy PECULIUM: Cochleae semi-hermeticae compressores cum operatione economizer boost efficientiam. Summus efficientia importata caloris nummulariorum in gradibus humilibus et intermediis temperatura operationem industriae efficientis in tam partialibus quam plenis oneribus obtinent.
· Facultas modulationis: Unitas quattuor scaenae capacitatem temperantiae (25%, 50%, 75%, 100%) praebet et temperatio inexplicabilis ab 25% ad 100%.
Professional Energy-saving Operation Solutions: Customised refrigerationis processuum ad clientem requisita discriminatim, providens speciales fructus propriis necessitatibus accommodatos.

Aqua refrigerata cochlea chiller (Single compressor)
Aqua refrigerata cochlea chiller (Single compressor)
SW-
Type			100S	135S	175S	190S	235S	260S	300S	320S	350S	380S	415S	495S	520S	570S	620S	640S	740S	820S	870S	980S
Nominal refrigerationem facultatem		kW	98	135	175.6	191.1	233.3	255.6	301.1	317.8	347.8	380	415	495	521.1	571.1	617.8	642.2	741.8	821.1	871.7	981.8
Nominal refrigerationem facultatem		10⁴kcal/h	8.4	11.6	15.1	16.4	20.1	22	25.9	27.3	29.9	32.7	35.7	42.6	44.8	49.1	53.1	55.2	63.8	70.6	74.9	84.4
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		23	30	39	42	51	56	63	66	73	80	88	103	108	118	126	130	150	167	177	199
	Current Rated (A)		39.2	51.6	64.7	71	86.4	94.1	105.9	111.4	122.7	133.8	148.8	172.8	182.5	197.7	212.8	219.6	253	280.7	298.1	335.2
	Energy ordinationem		0-33%-66% -100%			0-25%-50%-75%-100%							0-25%-50%-75%-100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		16.9	23.2	30.2	32.9	40.1	44	518	54.7	59.8	65.4	71.4	85.1	89.6	98.2	106.3	110.5	128.6	141.2	150.8	169.9
	Aqua pressura gutta (kPa)		45	45	48	48	50	50	50	55	55	55	55	58	60	62	68	68	68	70	70	72
	Magnitudo (mm)		DN65		DN80		DN100				DN125		DN125		DN150					DN200
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		20.8	28.4	36.9	40.1	48.9	53.6	62.6	66	72.4	79.1	86.5	102.9	108.2	118.5	127.9	132.8	154.4	170	181.2	204.1
	Aqua pressura gutta (kPa)		42	42	45	45	48	48	48	52	52	52	55	56	58	60	65	65	65	68	68	70
	Magnitudo (mm)		DN65		DN80		DN100				DN125		DN125		DN150					DN200
Refrigerant	Type		R134A										R134A
Refrigerant	Refrigerantes volumen (kg)		20	25	32	35	40	46	53	55	60	65	70	85	90	100	110	120	140	165	170	185
altiore dimensionibus	Longitudo (mm)		2310	2350	2420	2690	2690	2690	3080	3080	3080	3080	3110	3340	3440	3440	3440	3440	3550	3550	3550	3550
	Latitudo (mm)		660	660	660	810	840	890	920	935	935	935	995	995	1000	1000	1080	1280	1280	1310	1310	1325
	Altitudo (mm)		1520	1550	1590	1600	1660	1660	1710	1710	1750	1750	1870	1930	2020	2020	2020	2090	2090	2240	2240	2270
Pondus	Apparatus pondus (kg)		850	1050	1150	1270	1340	1430	1640	1710	1780	1850	2080	2300	2570	2850	2900	3100	3450	4050	4230	4450
Pondus	Pondus operating (kg)		900	1150	1300	1420	1540	1670	1890	1930	1970	2050	2330	2550	2950	3000	3200	3450	3750	4450	4600	4850
Condition: aquae frigidae inlet/exitus temperie 12C/7℃; Aquam condensatam inlotus/exitu temperatus 30℃/35℃. Terminus temperatus: aquae frigidae exitus temperatus 5℃-15℃; aqua refrigerans diverticulum siccus 19℃-33℃.

Aquae refrigeratae cochleae frigidiores (compressores Duplex)

SW-
Type			830D	990D	1040D	1140D	1240D	1280D	1480D	1640D	1740D	1960D	830D	990D	1040D	1140D	1240D	1280D	1480D	1640D	1740D	1960D
Nominal refrigerationem facultatem		kW	830	990	1042.2	1142.2	1235.6	1284.4	1483.6	1642.2	1743.3	1963.6	830	990	1042.2	1142.2	1235.6	1284.4	1483.6	1642.2	1743.3	1963.6
Nominal refrigerationem facultatem		10⁴kcal/h	71.4	85.1	89.6	98.2	106.2	110.4	127.6	141.2	149.9	168.8	71.4	85.1	89.6	98.2	106.2	110.4	127.6	141.2	149.9	168.8
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A										Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		176	206	216	236	252	260	300	334	354	398	176	206	216	236	252	260	300	334	354	398
	Current Rated (A)		297.6	345.6	365	395.4	425.6	439.2	506	561.4	596.2	670.4	297.6	345.6	365	395.4	425.6	439.2	506	561.4	596.2	670.4
	Energy ordinationem		0-12.5%-25%-37.5%-...100%										0-12.5%-25%-37.5%-...100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		142.8	170.3	179.3	196.5	212.5	220.9	257.2	282.5	301.6	339.8	142.8	170.3	179.3	196.5	212.5	220.9	257.2	282.5	301.6	339.8
	Aqua pressura gutta (kPa)		65	68	68	70	70	72	72	73	73	75	65	68	68	70	70	72	72	73	73	75
	Magnitudo (mm)		DN150	DN200						DN250			DN150	DN200						DN250
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		173.9	207.5	218.5	239.4	259	269.2	313.5	344.4	367.6	408.4	173.9	207.5	218.5	239.4	259	269.2	313.5	344.4	367.6	408.4
	Aqua pressura gutta (kPa)		62	65	65	67	68	68	70	70	72	72	62	65	65	67	68	68	70	70	72	72
	Magnitudo (mm)		DN125*2		DN150*2					DN200*2			DN125*2		DN150*2					DN200*2
Refrigerant	Type		R134A										R134A
Refrigerant	Refrigerantes volumen (kg)		140	170	180	200	220	240	280	330	340	370	140	170	180	200	220	240	280	330	340	370
altiore dimensionibus	Longitudo (mm)		3800	3830	3830	4100	4100	4100	4550	4580	4680	4720	3800	3830	3830	4100	4100	4100	4550	4580	4680	4720
	Latitudo (mm)		1310	1360	1360	1390	1430	1500	1520	1530	1720	1720	1310	1360	1360	1390	1430	1500	1520	1530	1720	1720
	Altitudo (mm)		2100	2250	2250	2270	2280	2290	2500	2640	2640	2640	2100	2250	2250	2270	2280	2290	2500	2640	2640	2640
Pondus	Apparatus pondus (kg)		4000	4500	5300	6000	6300	7000	7300	8300	8450	8800	4000	4500	5300	6000	6300	7000	7300	8300	8450	8800
Pondus	Pondus operating (kg)		4450	4950	6050	6600	6800	7550	7850	8900	9100	9300	4450	4950	6050	6600	6800	7550	7850	8900	9100	9300
Conditio: Aquae refrigerationis diverticulum/exitus temperatura 0℃/-5℃, Aquae in sinum/exitus temperatura 30℃/35℃ condensantur. Terminus temperatus: Aquae frigidae exitus caliditatis 7℃~5℃, Aquae frigidae latibulum temperatura 19℃~33℃. Aqua refrigerata adici debet per 25% glycol aquam vel 20% calcii chloridi anti-gelu.

Aqua refrigerata cochlea chiller (compressor quattuor)

SW-
Type			2100Q	2300Q	2480Q	2570Q	2980Q	3300Q	3500Q	3950Q
Nominal refrigerationem facultatem		kW	2084.4	2284.4	2471.1	2568.9	2967.1	3284.4	3486.7	3927.1
		10⁴kcal/h	179.3	196.5	212.5	220.9	255.2	282.5	299.9	337.7
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		432	472	504	520	600	668	708	796
	Current Rated (A)		730	790.8	851.2	878.4	1012	1122.8	1192.4	1340.8
	Energy ordinationem		0-6.25%-12.5%-18.75%-..100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		358.2392.5424.6441.4509.8564.3599.1674.8
	Aqua pressura gutta (kPa)		95
	Magnitudo (mm)		DN2002DN2502
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		432.4473.6511.2530.7612.9679.1720.7811.5
	Aqua pressura gutta (kPa)		90
	Magnitudo (mm)		DN2002DN2502
Refrigerant	Type		R134A
	Refrigerantes volumen (kg)		360	400	440	480	560	660	680	740
altiore dimensionibus	Longitudo (mm)		4150	4150	4150	4620	4620	5000	5000	5000
	Latitudo (mm)		2600	2600	2600	2600	2600	2600	2600	2720
	Altitudo (mm)		2560	2560	2560	2600	2630	2650	2650	2700
Pondus	Apparatus pondus (kg)		10500	11800	12850	13800	14600	15200	16850	17500
	Pondus operating (kg)		12100	12500	13100	14300	15100	15800	17650	18800
Conditio: Aqua refrigerans diverticulum Voutlet temperatura 12℃/7℃ Condensata aqua inlet/exitus temperatus 30℃/35℃. Temperature terminus: aquae frigidae exitus temperies 5℃~15℃, aqua refrigerans aestuarium temperies 19℃~33℃.

Humilis temperatus aqua refrigeratum sarew chiller (Single compressor) -5℃

SW-
Type			60SX	80SX	105SX	115SX	140SX	150SX	180SX	190SX	210SX	225SX	245SX	300SX	310SX	340SX	370SX	385SX	450SX	490SX	525SX	590SX
Nominal refrigerationem facultatem		kW	58.9	80	105.3	113.7	138.9	152.6	180	189.5	208.4	225.3	247.4	294.7	311.6	341.1	369.5	384.2	447.4	490.5	524.2	590.5
Nominal refrigerationem facultatem		10⁴kcal/h	5.1	6.9	9.1	9.8	11.9	13.1	15.5	16.3	17.9	19.4	21.3	25.3	26.8	29.3	31.8	33	38.5	42.2	45.1	50.8
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		21	28	35	38	46	50	57	60	66	72	80	93	98	106	114	118	136	150	160	180
	Current Rated (A)		36.6	48	59.8	65.6	79.8	86.9	97	102	112.3	122.5	136.2	158.2	167	181	194.8	201	231.6	256.9	272.9	306.8
	Energy ordinationem		0-33%-66% -100%			0-25%-50%-75%-100%							0-25%-50%-75%-100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		10.9	14.8	19.5	21	25.7	28.2	33.3	35.1	38.6	41.7	45.8	54.5	57.6	63.1	68.4	71.1	82.8	90.7	97	109.2
	Aqua pressura gutta (kPa)		45	45	48	48	50	50	50	55	55	55	55	58	60	62	68	68	68	70	70	72
	Magnitudo (mm)		DN65		DN80		DN100				DN125		DN125		DN150					DN200
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		13.8	18.6	24.1	26.1	31.8	34.9	40.8	42.9	47.2	51.1	56.3	66.7	70.4	76.9	83.2	86.4	100.3	110.2	117.7	132.5
	Aqua pressura gutta (kPa)		42	42	45	45	48	48	48	52	52	52	55	56	58	60	65	65	65	68	68	70
	Magnitudo (mm)		DN65		DN80		DN100				DN125		DN125		DN150					DN200
Refrigerant	Type		R134A										R134A
Refrigerant	Refrigerantes volumen (kg)		20	25	32	35	40	46	53	55	60	65	70	85	90	100	110	120	140	165	170	185
altiore dimensionibus	Longitudo (mm)		2310	2350	2420	2690	2690	2690	3080	3080	3080	3080	3110	3340	3440	3440	3440	3440	3550	3550	3550	3550
	Latitudo (mm)		660	660	660	810	840	890	920	935	935	935	995	995	1000	1000	1080	1280	1280	1310	1310	1325
	Altitudo (mm)		1520	1550	1590	1600	1660	1660	1710	1710	1750	1750	1870	1930	2020	2020	2020	2090	2090	2240	2240	2270
Pondus	Apparatus pondus (kg)		850	1050	1150	1270	1340	1430	1640	1710	1780	1850	2080	2300	2570	2850	2900	3100	3450	4050	4230	4450
Pondus	Pondus operating (kg)		890	1140	1290	1410	1530	1660	1800	1840	1880	1960	2240	2460	2860	2960	3050	3300	3600	4300	4450	4700
Condition: aquae frigidae inlet/exitus temperatus 0℃/-5℃; Aquae diverticulum condensate/exitus temperatus 30℃/35℃ Temperature terminus: Aquae frigidae exitus temperatus -7℃~5℃; Aqua refrigerans limbum temperatum 19℃~33℃.Aqua frigida adici debet 25% aqua glycol vel 20% calcii chloridi ut anti-gelu.

Aqua caliditas frigidissima refrigeratum sarew frigidum (Dupplex compressores) -5℃

SW-
Type			120DX	160DX	210DX	230DX	280DX	300DX	360DX	380DX	420DX	450DX	490DX	600DX	620DX	680DX	740DX	770DX	900DX	980DX	1050DX	1180DX
Nominal refrigerationem facultatem		kW	117.9	160	210.5	227.4	277.9	305.3	360	378.9	416.8	450.5	494.7	589.5	623.2	682.1	738.9	768.4	894.7	981.1	1048.4	1181.1
Nominal refrigerationem facultatem		10⁴kcal/h	10.1	13.8	18.1	19.6	23.9	26.2	31	32.6	35.8	38.7	42.5	50.7	53.6	58.7	63.5	66.1	76.9	84.4	90.1	101.6
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		42	56	70	76	92	100	114	120	132	144	160	186	196	212	228	236	272	300	320	360
	Current Rated (A)		73.2	96	119.6	131.2	159.6	173.8	194	204	224.6	245	272.4	316.4	334	362	389.6	402	463.2	513.8	545.8	613.6
	Energy ordinationem		0-16.5%-33%-..100%			0-12.5%-25%-37.5%-..100%							0-12.5%-25%-37.5%-...100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		21.8	29.6	38.9	42.1	51.4	56.5	66.6	70.1	77.1	83.3	91.5	109.1	115.3	126.2	136.7	142.2	165.5	181.5	194	218.5
	Aqua pressura gutta (kPa)		50	50	52	52	54	54	55	55	58	60	65	68	68	70	70	72	72	73	73	75
	Magnitudo (mm)		DN100		DN125			DN150					DN150	DN200						DN250
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		27.5	37.2	48.3	52.2	63.6	69.7	81.5	85.8	94.4	102.3	112.6	133.4	140.9	153.8	166.3	172.8	200.7	220.3	235.4	265.1
	Aqua pressura gutta (kPa)		45	45	48	48	50	52	52	54	55	55	62	65	65	67	68	68	70	70	72	72
	Magnitudo (mm)		DN100		DN125	DN80*2	DN¹00*2				DN125*2		DN125*2		DN150*2					DN200*2
Refrigerant	Type		R134A										R134A
Refrigerant	Refrigerantes volumen (kg)		40	50	64	70	80	92	106	110	120	130	140	170	180	200	220	240	280	330	340	370
altiore dimensionibus	Longitudo (mm)		2950	2950	3250	3285	3285	3555	3540	3540	3800	3800	3800	3830	3830	4100	4100	4100	4550	4580	4680	4720
	Latitudo (mm)		1060	1085	950	1000	1050	1050	1100	1200	1260	1310	1310	1360	1360	1390	1430	1500	1520	1530	1720	1720
	Altitudo (mm)		1545	1620	1630	1785	1900	1915	1920	1920	2020	2050	2100	2250	2250	2270	2280	2290	2500	2640	2640	2640
Pondus	Apparatus pondus (kg)		1650	1850	2100	2300	2400	2600	3000	3050	3300	3750	4000	4500	5300	6000	6300	7000	7300	8300	8400	8550
Pondus	Pondus operating (kg)		1885	2135	2535	2635	2720	3070	3510	3560	3880	4130	4370	4870	5850	6550	6785	7535	7835	8885	9085	9285
Conditio: Aquarum refrigerationem in diverticulo/exitu temperatura 0℃/-5℃; Condensate aquam in sinum/exitu temperatura 30℃/35℃ Temperature terminus: Aquae frigidae exitus temperatus -7℃~5℃; Aquam frigidam inloti temperie 19℃-33℃. Aqua refrigerata adici debet per 25% glycol aquam vel 20% calcii chloridi anti-gelu.

Humilis temperatus aqua refrigeratum sarew chiller (Single compressor) -15℃

SW-
Type			40SY	55SY	75SY	80SY	100SY	105SY	125SY	130SY	140SY	155SY	170SY	200ASY	210SY	230SY	250SY	260SY	300SY	330SY	360SY	400SY
Nominal refrigerationem facultatem		kW	40	55	75	80	100	105	125	130	140	155	170	200	210	230	250	260	300	330	360	400
Nominal refrigerationem facultatem		10⁴kcal/h	3.4	4.7	6.4	6.9	8.6	9	10.7	11.2	12	13.3	14.6	17.2	18.1	19.8	21.5	22.4	25.8	28.4	31	34.4
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		19	25	30	34	42	45	50	53	58	64	71	82	87	94	101	105	123	136	145	160
	Current Rated (A)		32.9	43.3	54.4	59.6	72.6	79.1	89	93.6	103.1	112.4	125.1	145.2	153.3	166.1	178.8	184.5	212.6	235.9	250.5	281.7
	Energy ordinationem		0-33%-66% -100%			0-25%-50%-75%-100%							0-25%-50%-75%-100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		8	11.1	15.1	16.1	20.1	21.1	25.1	26.1	28.1	31.2	34.2	40.2	42.2	46.2	50.3	52.3	60.3	66.3	72.4	80.4
	Aqua pressura gutta (kPa)		48	48	48	50	50	52	52	55	55	55	55	55	58	60	60	65	65	72	74	74
	Magnitudo (mm)		DN50				DN65				DN80		DN100				DN125
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		10.1	13.8	18.1	19.6	24.4	25.8	30.1	31.5	33.2	37.7	41.5	48.5	51.1	55.7	60.4	62.8	72.8	80.2	86.9	96.3
	Aqua pressura gutta (kPa)		45	45	46	48	48	50	50	53	53	53	54	54	56	58	58	62	62	70	72	72
	Magnitudo (mm)		DN50		DN65		DN80				DN100		DN100		DN125					DN150
Refrigerant	Type		R134A										R134A
Refrigerant	Refrigerantes volumen (kg)		16	22	25	30	35	40	45	50	53	56	60	65	70	80	90	95	110	125	135	145
altiore dimensionibus	Longitudo (mm)		2350	2350	2700	2700	2850	2850	3000	3000	3020	3020	3020	3300	3400	3400	3400	3400	3550	3550	3550	3550
	Latitudo (mm)		680	680	730	750	850	850	905	905	920	950	980	980	1000	1000	1050	1050	1130	1250	1250	1300
	Altitudo (mm)		1300	1300	1510	1550	1600	1600	1670	1670	1730	1750	1770	1890	2010	2010	2010	2010	2090	2200	2200	2250
Pondus	Apparatus pondus (kg)		830	1030	1120	1240	1310	1390	1600	1670	1740	1810	2040	2250	2520	2800	2850	3030	3380	3780	4160	4380
Pondus	Pondus operating (kg)		1030	1230	1320	1490	1560	1640	1850	1970	2040	2110	2340	2550	2820	3100	3200	3250	3430	3980	4380	4560
Condition: aquae frigidae inlet/exitus temperatus -10℃/-15℃; Aquam condensatam inlotus/exitu temperatus 30℃/35℃. Terminus temperatus: Aquae frigidae exitus temperatus -17℃~-7℃; Aquam frigidam inlitus temperies 19℃~33℃. Aqua frigida adici debet aqua glycol 40% vel 25% calcii chloridi ut anti-gelida.

Aquae caliditatis frigidissimae cochleae frigidioris refrigeratae (Dupplex compressores) -15℃

Sw-
Type			80DY	110DY	150DY	160DY	200DY	210DY	250DY	260DY	280DY	310DY	340DY	400DY	420DY	460DY	500DY	520DY	600DY	660DY	720DY	800DY
Nominal refrigerationem facultatem		kW	80	110	150	160	200	210	250	260	280	310	340	400	420	460	500	520	600	660	720	800
Nominal refrigerationem facultatem		10⁴kcal/h	6.9	9.5	12.9	13.8	17.2	18.1	21.5	22.4	24.1	26.7	29.2	34.4	36.1	39.6	43	44.7	51.6	56.7	61.9	68.8
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		38	50	60	68	84	90	100	106	116	128	142	164	174	188	202	210	246	272	290	320
	Current Rated (A)		65.8	86.6	108.8	119.2	145.2	158.2	178	187.2	206.2	224.8	250.2	290.4	306.6	332.2	357.6	369	425.2	471.8	501	563.4
	Energy ordinationem		0-16.5%-33%-..100%			0-12.5%-25%-37.5%...100%							0-12.5%-25%-37.5%-..100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		16.1	22.1	30.2	32.2	40.2	42.2	50.3	52.3	56.3	62.3	68.3	80.4	84.4	92.5	100.5	104.5	120.6	132.7	144.7	160.8
	Aqua pressura gutta (kPa)		50	50	54	54	58	58	60	60	63	63	65	75	80	85	85	90	90	95	110	115
	Magnitudo (mm)		DN65		DN80		DN100			DN125			DN125	DN150						DN200
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		20.3	27.5	36.1	39.2	48.8	51.6	60.2	63	66.4	75.3	82.9	97	102.2	111.5	120.7	125.6	145.5	160.3	173.7	192.6
	Aqua pressura gutta (kPa)		45	45	48	48	52	52	55	55	58	58	58	60	60	60	65	65	70	70	72	74
	Magnitudo (mm)		DN80		DN100	DN65*2	DN80*2				DN100*2		DN100*2		DN125*2					DN150*2
Refrigerant	Type		R134A
Refrigerant	Refrigerantes volumen (kg)		32	44	50	60	70	80	90	100	106	112	120	130	140	160	180	190	220	250	270	290
altiore dimensionibus	Longitudo (mm)		2950	2950	2950	3150	3150	3150	3570	3570	3570	3570	3700	3700	3700	3700	3700	4500	4500	4500	4900	4900
	Latitudo (mm)		1140	1140	1200	1000	1050	1050	1100	1100	1200	1250	1310	1310	1350	1350	1400	1400	1550	1550	1550	1600
	Altitudo (mm)		1480	1480	1500	1800	1850	1850	1850	1850	1900	1900	2150	2150	2380	2400	2400	2400	2470	2470	2470	2470
Pondus	Apparatus pondus (kg)		1500	1700	1950	2150	2250	2450	2850	2900	3050	3500	3750	4250	5050	5750	5850	6550	6850	7850	7950	8100
Pondus	Pondus operating (kg)		1785	2035	2435	2535	2620	2970	3410	3460	3680	3930	4170	4670	5650	6350	6385	7135	7435	8485	8685	8885
Conditio: aqua refrigerans diverticulum/exitus temperatus 10℃/-15℃;condensatus aqua limbum/exitus temperatus 30℃/35℃ Terminus temperatus: Aquae frigidae exitus 17~-7℃; Aquam frigidam inlitus temperies 19℃~33℃. Aqua frigida adici debet aqua glycol 40% vel 25% calcii chloridi ut anti-gelida.

Lowtemperature aqua refrigerata sarew chiller (Single compressor) -25℃
sw-
Type			30ST	40ST	50ST	55AT	70ST	75ST	90ST	95ST	100ST	HOST	120ST	145ST	155ST	170ST	180ST	190ST	220ST	240ST	260ST	290ST
Nominal refrigerationem facultatem		kW	30	40	52	56	68	75	88.5	93.5	102	110	122	145	153	168	182	187	220	241	258	290
Nominal refrigerationem facultatem		10⁴kcal/h	2.6	3.4	4.3	4.7	6	6.4	7.3	7.7	8.6	9.5	10.5	12.5	13.2	14.4	15.6	16.1	18.9	20.7	22.2	24.9
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		19.5	25.5	32	36.5	44	48.4	54.4	57.3	63	68.8	76.5	88.9	93.8	101.7	109.4	112.9	130	144	153	172
	Current Rated (A)		33	43.6	54.6	62.3	75.8	82.6	93	97.8	107.7	117.5	130.6	151.7	160.2	173.5	186.8	192.8	222.1	246.4	261.7	294.2
	Energy ordinationem		0-33%-66% -100%			0-25%-50%-75%-100%							0-25%-50%-75%-100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		6.4	8.5	10.6	11.7	14.8	15.9	18	19.1	21.2	23.3	25.4	29.7	31.8	35	37.1	39.2	44.5	49.8	53	59.4
	Aqua pressura gutta (kPa)		48	48	48	50	50	52	52	55	55	55	55	55	58	60	60	65	65	72	74	74
	Magnitudo (mm)		DN50				DN65				DN80		DN100				DN125
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		8.6	11.4	14.1	15.5	19.6	21	23.7	24.9	27.7	30.3	33.4	38.9	41.3	45.2	48.2	50.6	58.1	64.8	68.8	76.7
	Aqua pressura gutta (kPa)		45	45	46	48	48	50	50	53	53	53	54	54	56	58	58	62	62	70	72	72
	Magnitudo (mm)		DN50		DN65		DN80				DN100		DN100		DN125					DN150
Refrigerant	Type		R134A										R134A
Refrigerant	Refrigerantes volumen (kg)		7.7	10.2	14.1	15.4	19.2	20.5	23	24.3	26.9	29.4	32	38.4	39.7	43.5	47.3	48.6	56.3	62.7	67.8	75.5
altiore dimensionibus	Longitudo (mm)		2450	2450	2700	2850	2850	2850	2850	3250	3250	3250	3250	3250	3250	3250	3250	3650	3650	3650	3800	3800
	Latitudo (mm)		660	660	660	890	890	920	920	920	960	985	1000	1050	1050	1050	1100	1130	1130	1250	1250	1300
	Altitudo (mm)		1450	1590	1590	1600	1690	1690	1690	1690	1750	1750	1750	1752	1770	1770	1770	1870	1870	1870	1870	1950
Pondus	Apparatus pondus (kg)		880	1080	1170	1290	1360	1440	1650	1720	1790	1860	2090	2300	2570	2850	2900	3080	3430	4030	4210	4430
Pondus	Pondus operating (kg)		1160	1360	1450	1620	1690	1770	1980	2140	2210	2280	2510	2720	2990	3270	3370	3450	3630	3980	4580	4760
Conditio: aqua frigida inletus/exitus temperatus-20℃/-25℃; Aquam condensatam inlotus/exitu temperatus 30℃/35℃. Temperatus terminus: Aquae frigidae exitus temperatus 27℃~17℃; Aquam frigidam collyrium temperatura 19℃-33℃; Aqua frigida adjicienda est per 50% glycol aquam vel 27% calcii chloridi ut opus erat.

Aquae caliditatis frigidissimae cochleae frigidioris refrigeratae (Dupplex compressores) -25℃

Sw-
Type			60DT	80DT	100DT	110DT	140DT	150DT	180DT	190DT	200DT	220DT	240DT	290DT	310DT	340DT	360DT	380DT	440DT	480DT	520DT	580DT
Nominal refrigerationem facultatem		kW	60	80	104	112	136	150	177	187	204	220	244	290	306	336	364	374	440	482	516	580
Nominal refrigerationem facultatem		10⁴kcal/h	5.2	6.9	8.6	9.5	12	12.9	14.6	15.5	17.2	18.9	21	24.9	26.3	28.9	31.3	32.2	37.8	41.4	44.4	49.9
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		39	51	64	73	88	96.8	108.8	114.6	126	137.6	153	177.8	187.6	203.4	218.8	225.8	260	288	306	344
	Current Rated (A)		66	87.2	109.2	124.6	151.6	165.2	186	195.6	215.4	235	261.2	303.4	320.4	347	373.6	385.6	444.2	492.8	523.4	588.4
	Energy ordinationem		0-16.5%-33%-...100%			0-12.5%-25%-37.5%-..100%							0-12.5%-25%-37.5%-..100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		12.7	17	21.2	23.3	29.7	31.8	36	38.2	42.4	46.6	50.9	59.4	63.6	70	74.2	78.4	89	99.6	106	118.7
	Aqua pressura gutta (kPa)		50	50	54	54	58	58	60	60	63	63	65	75	80	85	85	90	90	95	110	115
	Magnitudo (mm)		DN65		DN80		DN100			DN125			DN125	DN150						DN200
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		17.2	22.7	28.2	31	39.2	42	47.5	49.9	55.4	60.5	66.7	77.7	82.6	90.5	96.3	101.1	116.3	129.7	137.6	153.4
	Aqua pressura gutta (kPa)		45	45	48	48	52	52	55	55	58	58	54	54	56	58	58	62	62	70	72	72
	Magnitudo (mm)		DN50*2		DN65*2		DN80*2				DN100*2		DN100*2		DN125*2					DN150*2
Refrigerant	Type		R134A
Refrigerant	Refrigerantes volumen (kg)		15.4	20.5	28.1	30.7	38.4	40.9	46.1	48.6	53.7	58.9	64	76.8	79.3	87	94.7	97.2	112.6	125.4	135.6	151
altiore dimensionibus	Longitudo (mm)		3570	3570	3570	3570	3570	3570	3570	3570	3570	4100	4100	4100	4500	4500	4500	4500	4500	4500	4900	4900
	Latitudo (mm)		1050	1100	1190	1190	1240	1280	1320	1320	1380	1400	1400	1400	1450	1500	1500	1500	1550	1550	1550	1550
	Altitudo (mm)		1530	1530	1540	1580	1650	1650	1650	1650	1700	2100	2150	2150	2380	2400	2400	2400	2470	2470	2470	2470
Pondus	Apparatus pondus (kg)		1700	1900	2150	2350	2450	2650	3050	3100	3350	3800	4050	4550	5350	6050	6150	6850	7150	8150	8250	8400
Pondus	Pondus operating (kg)		2235	2485	2885	2985	3070	3420	3860	3910	4180	4430	4670	5170	6050	6750	6785	7535	7835	8885	9085	9285
Conditio: Aquam Refrigerationem/exitus, temperies-20℃/-25℃; Condensare aquam in limbum/outiet temperies 30℃/35℃ Terminus temperatus: Aquae frigidae exitus caliditatis-27℃~17℃; Aquam frigidam collyrium temperatura 19℃-33℃; Aqua frigida adjicienda est per 50% glycol aqua or27% calcii chloridi ut opus erat.

Humilis temperatus aqua cooledscrew chiller (Single compressor) -35℃

Sw-
Type			16SZ	22SZ	29SZ	32SZ	40SZ	43SZ	50SZ	53SZ	58SZ	63SZ	69SZ	82SZ	87SZ	95SZ	103SZ	107SZ	123SZ	137SZ	148SZ	165SZ
Nominal refrigerationem facultatem		kW	16	22	29	32	40	43	50	53	58	63	69	82	87	95	103	107	123	137	148	165
Nominal refrigerationem facultatem		10⁴kcal/h	1.4	1.9	2.5	2.8	3.4	3.7	4.3	4.6	5	5.4	5.9	7.1	7.5	8.2	8.9	9.2	10.6	11.8	12.7	14.2
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		17	23	29	31	39	42	48	50	55	60	66	78	82	90	97	100	116	129	138	153
	Current Rated (A)		30.2	41.1	53.7	57	71.7	73.5	82.7	88.7	97.6	104.2	111.9	131.9	142.7	155.5	165.2	172.1	201.2	220.8	238	265.1
	Energy ordinationem		0-33%-66% -100%			0-25%-50%-75%-100%							0-25%-50%-75%-100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		3.5	4.9	6.4	7.1	8.8	9.5	11.1	11.7	12.8	13.9	15.2	18.1	19.2	21	22.8	23.6	27.2	30.3	32.7	36.5
	Aqua pressura gutta (kPa)		45	45	47	47	48	50	50	52	52	54	58	58	60	60	62	65	68	70	70	72
	Magnitudo (mm)		DN40				DN50				DN65		DN80				DN100
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		5.7	7.7	10	10.8	13.6	14.6	16.9	17.7	19.4	21.2	23.2	27.5	29.1	31.8	34.4	35.6	41.1	45.8	49.2	54.7
	Aqua pressura gutta (kPa)		35	35	46	46	47	48	48	50	50	50	55	57	58	58	60	62	65	68	68	70
	Magnitudo (mm)		DN40		DN50		DN65				DN80		DN80		DN100					DN125
Refrigerant	Type		R134A
Refrigerant	Refrigerantes volumen (kg)		4.3	5.9	7.8	8.6	10.8	116	13.5	14.3	15.6	17	18.6	22.1	23.4	25.6	27.7	28.8	33.1	36.9	39.9	44.4
altiore dimensionibus	Longitudo (mm)		2450	2450	2700	2850	2850	2850	2850	3250	3250	3250	3250	3250	3250	3250	3250	3650	3650	3650	3800	3800
	Latitudo (mm)		660	660	660	890	890	920	920	920	960	985	1000	1050	1050	1050	1100	1130	1130	1250	1250	1300
	Altitudo (mm)		1450	1590	1590	1600	1690	1690	1690	1690	1750	1750	1750	1752	1770	1770	1770	1870	1870	1870	1870	1950
Pondus	Apparatus pondus (kg)		880	1080	1170	1290	1360	1440	1650	1720	1790	1860	2090	2300	2570	2850	2900	3080	3430	3930	4210	4430
Pondus	Pondus operating (kg)		1140	1340	1430	1600	1670	1750	1960	2120	2190	2260	2490	2700	2955	3235	3335	3415	3580	4130	4530	4710
Conditio: aqua frigida inletus/exitus temperatus-30℃/-35℃; Aquae distillationis condensata / exitus temperatura 30℃/35℃. Temperature terminus: Aquae frigidae exitus temperatus -37℃~-27℃; Aquam frigidam collyrium temperatura 19℃-33℃; Aqua frigida adicienda est per 57% glycol aquam vel 30% calcii chloridi ut opus erat.

Aquae caliditatis frigidissimae cochleae frigidioris refrigeratae (Dupplex compressores) -35℃

Sw-
Type			32DZ	44DZ	58DZ	64DZ	80DZ	86DZ	100DZ	106DZ	116DZ	126DZ	138DZ	164DZ	174DZ	190DZ	206DZ	214DZ	246DZ	274DZ	296DZ	330DZ
Nominal refrigerationem facultatem		kW	32	44	58	64	80	86	100	106	116	126	138	164	174	190	206	214	246	274	296	330
Nominal refrigerationem facultatem		10⁴kcal/h	2.8	3.8	5	5.5	6.9	7.4	8.6	9.1	10	10.8	11.9	14.1	15	16.3	17.7	18.4	21.2	23.6	25.5	28.4
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		34	46	58	62	78	84	96	100	110	120	132	156	164	180	194	200	232	258	276	306
	Current Rated (A)		60.4	82.2	107.4	114	143.4	147	165.4	177.4	195.2	208.4	223.8	263.8	285.4	311	330.4	344.2	402.4	441.6	476	530.2
	Energy ordinationem		0-16.5%-33%-...100%			0-12.5%-25%-37.5%-..100%							0-12.5%-25%-37.5%-..100%
Evaporator	Type		Pipe arida alta efficientiam calor exchanger
	Flow(m³/h)		7.1	9.7	12.8	14.1	17.7	19	22.1	23.4	25.6	27.8	30.5	36.2	38.5	42	45.5	47.3	54.4	60.6	65.4	72.9
	Aqua pressura gutta (kPa)		50	50	52	52	54	54	55	58	58	60	62	64	64	64	65	68	68	70	70	72
	Magnitudo (mm)		DN50		DN65		DN80			DN100			DN100	DN125						DN150
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		11.4	15.5	20	21.7	27.2	29.2	33.7	35.4	38.9	42.3	46.4	55	58.1	63.6	68.8	71.2	82.2	91.5	98.4	109.4
	Aqua pressura gutta (kPa)		45	45	48	48	52	52	52	55	55	58	60	60	62	62	63	65	65	68	70	70
	Magnitudo (mm)		DN40*2		DN50*2		DN65*2				DN80*2		DN80*2		DN100*2					DN125*2
Refrigerant	Type		R134A
Refrigerant	Refrigerantes volumen (kg)		8.6	11.9	15.6	17.2	21.5	23.2	26.9	28.5	31.2	33.9	37.2	44.2	46.9	51.2	55.5	57.6	66.3	73.8	79.7	88.9
altiore dimensionibus	Longitudo (mm)		3570	3570	3570	3570	3570	3570	3570	3570	3570	4100	4100	4100	4500	4500	4500	4500	4500	4500	4900	4900
	Latitudo (mm)		1050	1100	1190	1190	1240	1280	1320	1320	1380	1400	1400	1400	1450	1500	1500	1500	1550	1550	1550	1550
	Altitudo (mm)		1530	1530	1540	1580	1650	1650	1650	1650	1700	2100	2150	2150	2380	2400	2400	2400	2470	2470	2470	2470
Pondus	Apparatus pondus (kg)		1625	1825	2065	2265	2365	2555	2955	3005	3255	3705	3955	4450	5250	5950	6250	6930	7230	8230	8330	8480
Pondus	Pondus operating (kg)		1845	2045	2285	2535	2635	2825	3225	3325	3575	4025	4275	4770	5570	6270	6700	7380	7680	8680	8780	8930
Conditio: aqua frigida inletus/exitus temperatus-20℃/-25℃; Aquam condensatam inlotus/exitu temperatus 30℃/35℃. Temperatus terminus: Aquae frigidae exitus temperatus 27℃~17℃; Aquam frigidam collyrium temperatura 19℃-33℃; Aqua frigida adicienda est per 57% glycol aquam vel 30% calcii chloridi ut opus erat.

Aqua refrigerata cochlea una compressor duos scaena chiller (-45℃)
SW-
Type			35SLT	38SLT2	48SLT	50SLT2	125SLT	135SLT2
Nominal refrigerationem facultatem		kW	35	38	48	50	125	135
Nominal refrigerationem facultatem		10⁴kcal/h	3	3.3	4.1	4.3	10.7	11.6
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Compressor	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigeratio initus (kW)		33	37	40	46	116	131
	Current Rated (A)		56	64	68	78	196.5	222
	Energy ordinationem		0-25%-50%-75%-100%
Evaporator	Type		Aliquam ferro excelsum efficientiam calor exchanger
	Flow(m³/h)		16	17	22	24	58	62
	Aqua pressura gutta (kPa)		95	95	95	95	120	120
	Magnitudo (mm)		DN80	DN80	DN80	DN80	DN125	DN125
Condenser	Type		Pipe princeps efficientiam calor exchanger
	Flow(m³/h)		20	20	28	28	72	78
	Aqua pressura gutta (kPa)		80	80	80	80	46	46
	Magnitudo (mm)		DN80	DN80	DN80	DN80	DN150	DN150
Refrigerant			R134A
altiore dimensionibus	Longitudo (mm)		2880	2880	3200	3200	4100	4100
	Latitudo (mm)		1100	1100	1100	1100	1300	1300
	Altitudo (mm)		1650	1680	1800	1850	2100	2150
Pondus	Apparatus pondus (kg)		1280	1330	1850	1920	4500	4560
Pondus	Pondus operating (kg)		1380	1420	2020	2080	4950	5050
Conditio aquae frigidae inletus/exitus temperatus -40℃ /-45℃ Aquae condensatae limbum/exitus temperatus 30℃/35℃. Terminus temperatus: Aquae frigidae exitus temperatus -47℃~-37°C; Aqua frigida refrigerans temperatura 19℃~33℃. Aqua frigida adjicienda est per 60% glycol aqua sicut anti-gelida.

Aquae refrigeratae cochleae cascade chiller (-55°C)
SW-
Type			65DFD	90DFD	125DFD	170DFD	210DFD	250DFD	330DFD
Nominal refrigerationem facultatem		kW	65	90	125	170	210	250	330
Nominal refrigerationem facultatem		10⁴kcal/h	5.6	7.7	10.7	14.6	18.1	21.5	28.4
Curre imperium			Usus PLC microcomputer imperium
Potestas Supple			380V/3N/50HZ
Satus genus			Y-A
Humilis pressura gradu	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigerant		R23
	Refrigerate		Ethanol
	Refrigeratio initus virtutis (kW)		30	39	52	69	82	98	125
	Current Rated (A)		70	93	128	172	205	245	315
	Flow(m³/h)		27.7	38.4	53.3	72.5	89.6	106.6	140.7
	Aqua pressura gutta (kPa)		95	100	100	110	110	120	120
	Magnitudo (mm)		DN80	DN80	DN100	DN100	DN125	DN125	DN150
	Evaporator		Princeps efficientiam caloris immaculatam ferro exchanger
Princeps pressura gradu	Type		Semi-clausis V: VI asymmetrica geminae stupra compressor
	Refrigerant		R134A/R404A
	Refrigeratio initus virtutis (kW)		46	60	80	105	130	160	205
	Current Rated (A)		121	153	202	265	335	390	500
	Flow(m³/h)		28	38	51	69	85	102	132
	Aqua pressura gutta (kPa)		70	70	70	75	75	80	80
	Magnitudo (mm)		DN80	DN80	DN100	DN100	DN125	DN125	DN150
	Condenser		Pipe princeps efficientiam calor exchanger
altiore dimensionibus	Longitudo (mm)		3000	3000	3200	3200	3200	5000	5000
	Latitudo (mm)		1800	1800	1800	1800	1800	1900	1900
	Altitudo (mm)		1750	1800	1800	1850	1950	2250	2450
Apparatus pondus (kg)			1850	2100	2300	2600	2800	3900	4500
Condition: aquae frigidae inlet/exitus temperatus -50℃/-55℃; Aquam condensatam inlotus/exitu temperatus 30℃/35℃. Terminus temperatus: Aquae frigidae exitus temperatus -57℃~-47℃; Aquam frigidam inlitus temperies 19℃~33℃. Aqua frigida ut anti-gelida addatur ethanol.

Shanghai Soouney Refrigeration Equipment Co., Ltd.

About Soouney.

Technological Probatio in Refrigeration Sector Industrial

Shanghai Soouney Refrigeration Equipment Co., Ltd. is a large-to-medium-sized high-tech enterprise within Shanghai's refrigeration sector, integrating research, development, production and sales. We are China Ambient Temperature Cryogenic Single Compressor Duplex Compressors Aqua refrigerata stupra Chiller Suppliers and Wholesale Ambient Temperature Cryogenic Single Compressor Duplex Compressors Aqua refrigerata stupra Chiller Company. Upholding the quality principles of 'integrity, quality, service and innovation', the company pursues a development philosophy centred on humanisation and technological advancement, driving product R&D and manufacturing with high starting points and stringent standards. It has now grown into a renowned brand in the domestic and international markets for cabinet air conditioners and industrial chillers, earning high recognition from industry professionals and a broad customer base. Rooted in the Chinese market, it provides reliable refrigeration solutions to clients worldwide. We focus on international trade and B2B business, providing tailored solutions to global clients. We ensure the smooth, stable, and long-term operation of your projects with a comprehensive research and development, production, sales, and after-sales service system. We have nearly 20 years of experience in providing one-stop solutions for overseas projects.

0

Site Area
0

statutum
0+

Employees

2026-08-12 Industria News
Indoor arca Aeris Conditioner: Features, Applications, et ...
Electronica celerius in calore deficiunt quam fere alia via. An indoor arca aer Conditioner nominatim exsistit prohibere ne fieret, signantes electronicas intra clausuram vel automationem clausurae moderaminis et ansam refrigerationem clausam currentem, quae nusq...
Learn More
2026-08-05 Industria News
Scrinium Air Conditioner Unit: Features, Applications, et ...
A Scrinium Air Conditioner Unit systema refrigerationis compacta directe ascendit in clausura electrica ad custodiendum PLCs, impellit, et intra componentes temperantiae temperatae tutae operativae. Dissimilis locus aer conditionator, numquam extra aerem cum scri...
Learn More
2026-07-29 Industria News
Machina Room Cabinet Air Conditioner: Applications, Benefi...
Electronic components in ambitibus calidis, pulverulentis velocius deficiunt quam paene alia condicio industrialis cubiculi imperium facies. A machina locus scrinium aer Conditioner utraque simul problemata solvit, clausuram obsignatam tenens ad temperaturam stab...
Learn More

Industria scientia

Quomodo facit aquam Cryogenic refrigeratam Screw Chiller Consequi Ultra-low Temperaturis?

In recentioribus applicationibus refrigerationis industriae, quae temperaturae ultra-lowestatem attingens non est simpliciter materia refrigerandi capacitatis augendae - requirit accuratam potestatem thermodynamicam, architecturae systematis propriae, et integrationem componentis provectam. The cryogenic aqua refrigeratum stupra chiller solutionem elegantissimam repraesentat, quae in condiciones temperatae extremae efficienter operantur, servata stabilitate, constantia et industria efficientiae.

Fundamental Frigus Principium

In suo nucleo, aqua cryogenica refrigerata cochleae chiller operatur secundum compressionem vaporis cycli refrigerationis, auctus per compressionem multi-statis, electio refrigerantis optimized, et accurata procuratio scelerisque.

Pentium Processus Overview

Scaena	Descriptio	Munus
Cogo	Vapor gravis caloris refrigerandi comprimitur	Pressura et temperatus
Condensatio	Calor reicitur per refrigerationem aquae	Conversus vapor in liquidum
Expansion	Pressura mittit expansion per fabrica	Facit humilis temperatus refrigerandi
Evaporatio	Refrigerant trahit calorem a processus medium	Pervenit ultra-low refrigerationem

Ut ad temperaturas cryogenicas perveniatur, ratio typice integrat cyclos multi-statis vel cascades refrigerationis, permittens paulatim reductionem temperaturae conservando efficientiam thermodynamicam.

Munus of Compressor Technology stupra

Cochlea compressor est nucleus incessus systematis. Compressores reciproci traditi comparati, compressionem continuam et stabilem cum tremore minimae praebet.

Clavis Commoda

Continua compressionem processus lenis operatio ensures
Princeps efficientiam volumetric melius refrigerium perficiendi
Lata onus aptabilitas variabilis operating conditionibus sustinet
Reducitur mechanica lapsum adducunt ratio longitudinis vitae

In aqua cryogenica refrigerata cochleae frigidioris, compressor saepe optimized ad refrigerantia humilis-temperatus, ad consistentiam perficiendi vel sub nimia pressione rationum procurans.

Multi scaena et Refrigeration Cascade Systems

Consequi ultra-low temperaturas plus quam unica refrigeratio ansam requirit. Pleraque systemata adhibent vel:

Multi scaena compressionem

Sequentiae compressionis gradus reducere scelerisque accentus
Improves efficientiam in inferioribus temperaturis evanescentibus
Regium industria damnum in operandi

Caesar Refrigeration

Utitur duobus vel pluribus circuitus REFRIGERATIO independent
Unusquisque intra meliorem temperatus range operetur
Commutatio caloris occurs inter gradus progressivos refrigerationis

Ratio Type	Structure	Temperature Capability	Efficientia
Unius scaena	Simple loop	Moderari humilis temperatus	Moderatus
Multi scaena	Compressio sequential	Infra temperatus range	Superius
Cascade systema	Plures ansas	Ultra humilis temperaturis	Optimal

Momentum aquae frigidae ratio

Dissimilis systemata aeris refrigerativi, refrigeratio aquae praebet superiorem calorem reiectionis efficientiam, quae est critica ad operationem cryogenicam.

Beneficia aquae frigidae

Superior calor translatio coefficientis
Condensatio stabilis temperatus
Improved system efficientiam sub oneribus
Reducitur ambientium temperatus impulsum

Condenser aquae refrigeratae efficit ut calor extrahatur e processu efficaciter removeatur, permittens refrigerans ut efficaciter condenset etiam in gradibus compressionis altae.

Refrigerant Electio Cryogenic euismod

Electio refrigerandi directe afficit ad rem deduceretur temperatus range et ratio efficientiae.

Key Considerationes

Humilis ferveret ad cryogenic applicationes
Princeps latens calor ad industriam efficientem transfer
Eget stabilitatem humilis temperaturis
Environmental obsequio

Refrigerant Property	Impact in System
fervens	Decernit minimum temperatus deduceretur
Latens calor	Refrigerium facultatem pertinet
Scelerisque status	Tutam operationem
Compatibilitas	Influit materia lectio

Provectus systemata temperata vel refrigerantia ridicula uti possunt ad perficiendum per diversas regiones temperaturas optimize.

Calor Exchange Efficens ac Design

Calor efficiens commutatio essentialis est ad consequendum ultra-low temperaturas.

Key Caloris Exchangers

Evaporator : calor absorbet a processu medium
Condenser : Dimittit calorem ad refrigerandum aquam
Medium calor exchanger (In Caesar systemata): Transfert calorem inter gradus

Design Features

Superficies amplificata est calor translationis ad improved
Optimized cursus cursus uniformis distribution
Corrosio repugnans materiae ad diuturnitatem

Materia Electio ad Operatio Low-Tempus

Condiciones cryogenicae strictas requisita in materiali effectu imponunt.

Materia Comparationis

Materia	commoda	Limitationes	Applicationem
Diver	Optimum corrosio resistentia	Superius cost	Calor nummulariorum
Aeris alloys	Princeps scelerisque conductivity	Maximum robur temps	Tubing
aluminium alloys	Leve et efficiente	Moderatus durability	Calor translationis components
Specialis polymerorum	Resistentia chemica	Temperatus limitations	elementa signantes

Electio materialis integritatem structuram efficit et fragilitatem impedit sub conditionibus frigidissimis.

Intelligentes Imperium et Automation

Aquae cryogenicae modernae refrigeratae cochleae chillers confidunt graviter in systemata potestate provecta ad accurate conservandum.

Imperium Ratio functiones

Cras placerat tempus tortor
Lorem onus temperatio
Pressura et influunt ordinationem
Salus tutela et culpa diagnostica

Haec systemata accuratam stabilitatem temperaturae efficiunt, quae critica est in industriis ut pharmaceuticis, chemicis, processui et fabricandis provectis.

Eget Capabilities and Industrial Applications

Eget Overview

Munus	Descriptio
Ultra humilis temperatus refrigerationem	Consequitur temperaturas longe infra conventional chillers
Continua operatio	Sustinet processus industriae 24/7
Energy ipsum	Reduces operational sumptibus
Processus stabilitatis	Stat scelerisque conditionibus

Typical Applications

Reactionem chemica refrigerationem
Pharmaceutical productio
Processus semiconductor
Aerospace materia temptationis
Humilis-temperatus systemata repono

Integration cum Industrial Systems

Aqua cryogenica refrigerata cochleae frigidioris saepe in plures systemata processus integratur.

Integration Features

Modulare consilium pro scalability
Compatibilitas cum existentium refrigerationem infrastructure
Flexibile configuration pro diversis industries

Shanghai Soouney Refrigeratio Apparatus Co, Ltd. agit munus vitale in hac technologia proficiendi. Ut summus tech inceptis integrandis R&D, productionibus et venditionibus, societas mercatum validum in campo refrigerationis industrialis collocavit. Eius peritia in cistula aeris conditionarii et chillers industriae suam profundam intelligentiam systematis integrationis ac perficiendi optimizationis refert.

Aliae refrigerationis industriae fabricatores ad innovationem systematis conferunt etiam per emendationes in consilio compressoris, calor commutationem efficientiam, technologias moderatio intelligentes, augendae insuper fidei refrigerationis systematis cryogenicae augendae.

Energy Efficiency Considerationes

Quamvis operandi in temperaturis valde demissis, systemata moderna ad efficientiam industriam destinata sunt.

Efficientiam Strategies

Variabilis frequency agit (VFDs)
Cogo rationes Optimized
Nulla ars provectae
Æstus recuperatio optiones

Hae lineamenta industriam consummationis minuunt, servato alta refrigeratione perficiendi.

conclusio

Aquae cryogenic refrigerata cochleae chiller ultra-low temperaturas per complexionem cyclorum thermodynamicorum progressorum consequitur, efficiens cochleae compressor technologiae, electio refrigerantis optimized, et summus effectus calor systematis commutationis. Facultas eius stabilitatem sub extremas condiciones servandi necessariam facit in industriarum praecisione agitatae.

Per integrationem intelligentium moderamina, materias robustas, et refrigerationem aquae efficientis, haec systemata certa et constanti operationi cryogenic tradenda, occurrens augmentum postulationis applicationis temperaturae ultra-humilis.

FAQ

1. Quid temperatura range potest consequi aquam cryogenicam refrigeratam cochleae frigidioris?
Pervenire potest ad temperaturas maxime humiles secundum rationem consiliorum, saepe longe infra conventionales Chillers industriales, praesertim cum systemata refrigerationis cascade utens.

2. Cur aqua refrigerans frigidis cryogenicis praefertur?
Aqua refrigeratio efficaciam caloris reiectionem et operationem stabilem praebet, quae est essentialis ad conservationem temperaturis ultra-humilis.

3. Quid industries vulgo utuntur aqua cryogenica refrigerata cochleae chillers?
Late adhibentur in pharmaceuticis, chemicis processus, vestibulum semiconductoribus et aerospace probatione.

4. Quomodo cochlea compressor in systematis cryogenicis emendavit?
Compressionem continuam et stabilem efficit cum efficientia et minima vibratione magna, eamque aptam facit ad applicationes humilis temperaturas exigendas.

5. Quae res afficiunt efficientiam frigidioris cryogenici?
Clavium factores includunt refrigerandi delectu, consilium compressoris, efficientiam commutatoris caloris, et optimizationem ratio temperantiae.

Provecta Vestibulum

Secundum Globally Ducens
Refrigeration Equipment Research
Signa progressio

Plene Automated Conventus Linearum

Adhibendis automated technologiae conventus augendae efficientiae et producti constantia.

Multi-Conditio Testis Platforms

Simulans productum perficientur sub variis ambitibus et conditionibus ad invigilandum fidem per applicationes.
